Specifications Ruijie Reyee RG-NBS5100-24GT4SFP-P
| Features | Specifications |
|---|---|
Switch |
|
| Product Type | 28-Port Gigabit Layer 3 Managed PoE Switch |
| Layer | Layer 3 |
| RJ45 Ports | 24 × 10/100/1000BASE-T |
| SFP Ports | 4 × 1G SFP |
| Switching Capacity | 56Gbps |
| Forwarding Rate | 41.66Mpps |
| MAC Address Table | 8K |
| Jumbo Frame | 9216 Bytes |
| MTBF | 400,000 Hours |
PoE |
|
| PoE Ports | 24 × PoE/PoE+ |
| PoE Standard | IEEE 802.3af/at |
| PoE Budget | 370W |
| Maximum PoE Power per Port | 30W |
| PoE Power Pins | 1–2 (+), 3–6 (-) |
| PoE Watchdog | Supported |
Management & Features |
|
| Management | Ruijie Cloud / Web Management |
| VLAN | Supported |
| Link Aggregation | Supported |
| IGMP Snooping | Supported |
| Port Isolation | Supported |
| Broadcast Storm Control | Supported |
| Layer 3 Features | Supported |
| Security | Multiple Network Security Policies |
Power & Environment |
|
| Power Supply | 100–240V AC, 50/60Hz |
| Maximum PoE Load | 370W |
| Fans | 2, Automatic Speed Adjustment |
| Operating Temperature | 0°C to +50°C |
| Surge Protection | ±6kV Common Mode on Service Ports |
| Warranty | 5 Years |
Note: The Ruijie Reyee RG-NBS5100-24GT4SFP-P is a 28-port Layer 3 managed PoE switch with 24 Gigabit PoE/PoE+ ports and 4 Gigabit SFP uplink ports. It provides a 370W PoE budget with up to 30W per port, 56Gbps switching capacity, Ruijie Cloud management, VLAN, link aggregation, IGMP snooping, port isolation and PoE watchdog functions. The switch also provides 6kV surge protection and supports a 9216-byte jumbo frame.
