| Features |
Description |
| Camera Type |
2MP Fixed Color Maker Turret Camera |
| Image Sensor |
1/2.8″ CMOS |
| Max. Resolution |
1920 × 1080 @ 30fps |
| Lens |
2.8mm Fixed Lens |
| Minimum Illumination |
0.002 Lux @ F1.6, AGC ON |
| IR Range |
Up to 30 m |
| Warm Light |
2 LEDs, up to 15 m |
| WDR |
120 dB |
| Video Compression |
S+265 / H.265 / H.264 |
| Video Analytics |
Tripwire and Perimeter Detection |
| Audio |
Built-in Microphone |
| Storage |
MicroSD up to 512GB |
| Network |
10/100 Mbps Ethernet, PoE |
| Protection |
IP66 |
| Camera |
| Image Sensor |
1/2.8″ CMOS |
| Signal System |
PAL / NTSC |
| Shutter Time |
1 s – 1/100,000 s |
| Day & Night |
IR-Cut Filter with Auto Switch (ICR) |
| Minimum Illumination |
Color: 0.002 Lux @ F1.6, AGC ON; B/W: 0 Lux with IR |
| Wide Dynamic Range |
120 dB |
| S/N Ratio |
>42 dB |
| Angle Adjustment |
Pan 0–340°, Tilt 0–75°, Rotation 0–360° |
| Lens |
| Lens Type |
Fixed |
| Focal Length |
2.8 mm |
| Lens Mount |
M12 |
| Aperture |
F1.6, Fixed |
| Horizontal Field of View |
100.6° |
| Vertical Field of View |
56.5° |
| Diagonal Field of View |
115.4° |
| DORI – Detect |
38.6 m |
| DORI – Observe |
15.3 m |
| DORI – Recognize |
7.7 m |
| DORI – Identify |
3.8 m |
| Illuminator |
| IR LEDs |
2 |
| IR Distance |
Up to 30 m |
| IR Wavelength |
850 nm |
| Smart IR |
Yes |
| Warm LEDs |
2 |
| Warm Light Distance |
Up to 15 m |
| Video & Image |
| Video Compression |
S+265 / H.265 / H.264B / H.264M / H.264H |
| Video Bit Rate |
32 Kbps – 6 Mbps |
| Maximum Resolution |
1920 × 1080 @ 30fps |
| Main Stream |
PAL: 25fps; NTSC: 30fps |
| Sub Stream |
PAL: 25fps; NTSC: 30fps |
| Third Stream |
N/A |
| BLC |
Yes |
| HLC |
Yes |
| AGC |
Yes |
| 3D DNR |
Yes |
| White Balance |
Auto / Semi-Auto / Manual / Sunny / Natural Light / Warm Light / Sodium Lamp / Incandescent / Locked |
| ROI |
8 Regions |
| OSD |
1 Region |
| Privacy Mask |
4 Regions |
| Smart Defog |
Yes |
| AI & Intelligent Functions |
| Video Analytics |
Tripwire, Perimeter |
| Behavior Analysis |
2 Rules in 1 Scene |
| Motion Detection |
Yes |
| Mask Alarm |
Yes |
| Alarm Trigger |
Motion Detection, Mask Alarm, Disk Full, Disk Read/Write Error, IP Address Conflict |
| Linkage Method |
Trigger Warm Light, Trigger Recording, Trigger Capture, Notify Surveillance Center |
| Early Warning |
N/A |
| Auto Tracking |
N/A |
| Face Detection |
N/A |
| Audio |
| Built-in Microphone |
Yes |
| Audio Input |
Built-in Microphone |
| Audio Output |
N/A |
| Audio Compression |
G.711A / G.711U / ADPCM_D |
| Audio Sampling Rate |
8 kHz / 32 kHz / 48 kHz |
| Network & Storage |
| Network Interface |
1 × RJ45 10/100 Mbps Self-Adaptive Ethernet Port |
| ANR |
Yes, Tiandy ANR NVR Only |
| Protocols |
HTTP, HTTPS, TCP/IP, UDP, UPnP, ICMP, DHCP, DNS, DDNS, Easy DDNS, NTP, QoS, IPv4, SSH, Unicast, RTSP, FTP |
| System Compatibility |
ONVIF Profile S/T/G, SDK, CGI, Milestone, P2P |
| Remote Connection |
Up to 2 Clients |
| PC Client |
Easy7 Smart Client |
| Mobile Client |
EasyLive Plus |
| Web Browser |
IE10+, Firefox 52+, Edge 89+, Safari 11+, Chrome 57+ |
| Storage |
Built-in MicroSD Card Slot, up to 512GB |
| Interface |
| Communication Interface |
1 × RJ45 10/100 Mbps |
| Audio I/O |
N/A |
| Alarm I/O |
N/A |
| Built-in Microphone |
Yes |
| Built-in Speaker |
N/A |
| Reset Button |
Yes |
| On-board Storage |
MicroSD up to 512GB |
| Additional Interfaces |
N/A |
| Power & General |
| Power Supply |
DC 12V ±25% / PoE IEEE 802.3af |
| Power Consumption |
Max. 6W (12V) / Max. 7W (PoE) |
| Operating Temperature |
-40°C to 65°C |
| Operating Humidity |
0–95% RH |
| Storage Temperature |
-40°C to 65°C |
| Protection |
IP66 |
| Surge Protection |
2000V |
| Lightning Protection |
6000V |
| Housing |
Metal |
| Dimensions |
117 × 117 × 96 mm |
| Package Dimensions |
140 × 140 × 120 mm |
| Net Weight |
0.47 kg |
| Gross Weight |
0.61 kg |
Note: Specifications are based on Tiandy TC-C32XP Spec:I3W/E/Y/M/2.8mm/V4.2 documentation.
Important: TC-C32XP has different hardware and specification versions. The V4.2 model supports 2.8mm fixed lens, Smart IR 30m, 2 warm lights up to 15m, DC12V/PoE and IP66. Verify the exact suffix before publication.
