Specifications TP-Link Omada EAP650-Desktop
| Features | Specifications |
|---|---|
| Product Type | AX3000 Desktop Dual-Band Wi-Fi 6 Access Point |
| Wireless Standard | IEEE 802.11a/b/g/n/ac/ax |
| Wireless Frequency | 2.4 GHz and 5 GHz |
| Wireless Speed | 2.4 GHz: Up to 574 Mbps 5 GHz: Up to 2402 Mbps Total: Up to 2976 Mbps |
| Ethernet Interface | 4× Gigabit Ethernet Ports |
| FXS Interface | 1× FXS Port |
| PoE Input | 802.3af/at/bt PoE |
| PoE Output | 1× Ethernet Port Supports PoE Out 802.3at/af Output with 802.3bt Input |
| DC Power Supply | 12V / 1.5A |
| Maximum Power Consumption | 17.3 W (PoE Out Off) |
| Antenna Type | Internal Omni-directional Antennas |
| Antenna Gain | 2.4 GHz: 2× 5 dBi 5 GHz: 3× 4.7 dBi |
| Wireless Technology | OFDMA, MU-MIMO, Beamforming, 1024-QAM and HE160 (160 MHz) |
| SSID Support | Up to 16 SSIDs (8 SSIDs per band) |
| Wireless Security | WPA-Personal/Enterprise, WPA2-Personal/Enterprise and WPA3-Personal/Enterprise |
| Network Features | VLAN, Guest Network, Band Steering, Load Balance, Airtime Fairness, Rate Limit and Client Isolation |
| Omada Features | Omada Mesh, Seamless Roaming, Captive Portal and Centralized Management |
| Management | Omada Hardware Controller, Software Controller, Cloud-Based Controller and Omada App |
| Concurrent Clients | 250+ |
| Wireless Coverage | Up to 140 m² (1500 ft²), depending on the environment |
| Mounting | Desktop and Wall Mounting |
| Dimensions (W × D × H) | 175 × 140 × 33 mm |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 10–90% RH, Non-condensing |
| Certifications | CE, FCC, RoHS and IC |
Important: PoE output requires an 802.3at/bt PoE power supply. Actual wireless coverage and performance may vary depending on environmental conditions and connected client devices.
