| Features |
Description |
| Device Type |
4MP Outdoor/Indoor Infrared Fixed Turret Network Camera |
| Brand / Series |
TP-Link / VIGI Professional Surveillance Series |
| Image Sensor |
1/3″ Progressive Scan CMOS |
| Maximum Resolution |
4 Megapixel (2560 × 1440) @ 30 fps |
| Lens Options |
2.8 mm or 4 mm fixed focal lens |
| Minimum Illumination |
Color: 0.005 Lux (F1.6, AGC ON); 0 Lux with IR |
| IR Range |
Up to 30m (98ft) Night Vision |
| Video Compression |
H.265+ / H.265 / H.264+ / H.264 |
| Protection |
IP67 Weatherproof |
| CAMERA |
| Sensor |
1/3″ Progressive Scan CMOS |
| Minimum Illumination |
Color: 0.005 Lux, 0 Lux with IR |
| Day/Night |
IR-Cut Filter with Auto Switch |
| Shutter |
Auto / Manual, 1/3 to 1/10000s |
| WDR |
Digital WDR (DWDR) |
| S/N Ratio |
>52 dB |
| LENS |
| Lens Type |
Fixed Focal Lens |
| Focal Length |
2.8 mm or 4 mm |
| Aperture |
F1.6 |
| Horizontal FOV |
2.8mm: 98°, 4mm: 78° |
| Vertical FOV |
2.8mm: 53°, 4mm: 42° |
| Diagonal FOV |
2.8mm: 116°, 4mm: 92° |
| VIDEO |
| Video Compression |
H.265+ / H.265 / H.264+ / H.264 |
| Main Stream |
2560 × 1440, 2304 × 1296, 2048 × 1280, 1920 × 1080, 1280 × 720 @ 30fps |
| Sub Stream |
720 × 576, 720 × 480, 352 × 288, 640 × 480 @ 30fps |
| Bit Rate Control |
CBR / VBR |
| ROI |
1 Fixed Region |
| Video Stream |
Dual Streams |
| IMAGE |
| Digital Noise Reduction |
3D DNR |
| BLC / HLC |
Supported |
| Image Settings |
Mirror, Saturation, Brightness, Contrast, Sharpness, White Balance, AGC adjustable by client software |
| SMART FEATURES |
| Smart Detection |
Human & Vehicle Classification, Motion Detection, Area Intrusion Detection, Line-Crossing Detection, Tampering Detection |
| Alarm Trigger |
Video Tampering, Network Disconnection, IP Address Conflict |
| Method of Linkage |
Trigger Notification, Snapshot, Video Recording |
| ILLUMINATOR |
| IR Range |
Up to 30m |
| Wavelength |
850nm |
| Light Control |
Auto / Manual |
| Smart IR |
Supported |
| STORAGE |
| Edge Storage |
Built-in MicroSD Card Slot, Support up to 256 GB |
| Network Storage |
NAS (NFS, SMB/CIFS) |
| NETWORK |
| Network Interface |
1 × RJ45 10/100M Self-Adaptive Ethernet Port |
| ONVIF |
Profile S |
| Network Protocol |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, NTP, RTSP, RTCP, PPPoE, SMTP, UPnP |
| Simultaneous Live View |
Up to 6 Channels |
| Security |
Password Protection, HTTPS Encryption, IP Address Filtering, Digest Authentication |
| AUDIO & ALARM |
| Audio Input |
Built-in Microphone (for audio monitoring) |
| Audio Output |
None |
| Alarm Input |
None |
| Alarm Output |
None |
| POWER & PROTECTION |
| Power Supply |
12V DC ± 10%, 5.5mm Coaxial Power Plug / PoE (802.3af/at, class 0) |
| Maximum Power Consumption |
12V DC: Max 3W; PoE: Max 4W |
| PHYSICAL & ENVIRONMENT |
| Dimensions |
Ø123 × 83 mm |
| Weight |
0.195 kg |
| Operating Temperature |
-30°C to 60°C |
| Operating Humidity |
95% or less (non-condensing) |
Note: The TP-Link VIGI C440 is a high-resolution 4MP outdoor/indoor infrared fixed turret network camera built for professional surveillance environments. It delivers ultra-sharp 4MP Quad HD video at 30 fps, advanced smart human and vehicle classification, a built-in microphone for audio monitoring, an on-board MicroSD card slot supporting up to 256GB, and H.265+ smart compression to reduce bandwidth and storage usage.
Important: The VIGI C440 features a 4MP resolution sensor in a turret enclosure with fixed lens options of 2.8mm or 4mm and a built-in MicroSD card slot for local recording up to 256GB. It includes robust Smart Detection capabilities for human and vehicle classification to minimize false alerts. Connectivity is handled through a 10/100M Ethernet interface with support for 12V DC or PoE (802.3af/at), and the unit carries an IP67 weatherproof rating for reliable performance in temperatures ranging from -30°C to 60°C.
