System

• Operation SystemLinux

Display

• Dimensions7-inch
• TypeLCD
• Operation MethodCapacitive touch screen

Video

• Pixel2 MP
• Lens2

Audio

• Tone QualityNoise suppression and echo cancellation

Network

• Wired Network10 M/100 M/1000 M self-adaptive

Interface

• Network Interface1
• RS-4851
• Wiegand1
• Lock Output1
• Exit Button1
• Door Contact Input1
• IO Input2
• IO Output1
• Power Interface2-pin
• TAMPER1
• USB2

Capacity

• Card Capacity6000
• Face Capacity6000
• Fingerprint Capacity5000
• Event Capacity50,000

Authentication

• Card TypeMifare 1 card
• Card Reading Frequency13.56MHz
• Card Reading Distance0 to 5 cm
• Face Recognition Accuracy Rate≥ 99%
• Face Recognition Distance0.3 to 3 m (Without face mask)
• Fingerprint Recognition Duration≤ 1 s

Function

• QR Code RecognitionSupport
• Face Anti-SpoofingSupport
• AdvertisementSupport
• Audio PromptSupport
• Time SynchronizationSupport

General

• Power Supply Method2-pin connecter
• Power Supply12 VDC/2 A
• Working Temperature-30 ℃ to 60 ℃ (-22 °F to 140 °F)
• Working Humidity10 to 90％ (No condensing)
• Dimensions290 mm × 116.5 mm × 33 mm (11.4″ × 4.6″ × 1.3″)
