System Parameters

• Operation SystemEmbedded Linux operation system
• Display Parameters
• Size10-inch
• Operation MethodPhysical button
• Typecolorful LCD
• Resolution600 × 1024
• Video Parameters
• Supplement Light

  IR supplement

• Video Compression StandardH.264
• Lens1
• FOV

  Horizontal: 108° , Vertical: 59°, Diagonal: 129°

• WDR

  True WDR

• Pixel

  Main stream : 1920 × 1080

  Sub stream : 720 × 480

• Audio Parameters
• Audio Compression StandardG.711 U
• Audio InputBuilt-in omnidirectional microphone
• Audio OutputBuilt-in loudspeaker
• Audio Compression Bitrate64 Kbps
• Audio QualityNoise suppression and echo cancellation
• Volume AdjustmentAdjustabel
• Capacity
• Fingerprint Capacity

  Optical fingerprint module, Max. 5000 fingerprints

• Face Capacity5000
• Linked Indoor Station500
• Network Parameters
• Communication Protocol

  TCP/IP, RSTP

• Wired Network10/100 Mbps self-adaptive Ethernet
• Wi-Fi/
• Bluetooth/
• Device Interfaces
• Network Interface1
• Exit Button1
• Lock Control2
• Door Contact Input1
• Power Interface1
• General
• InstallationFlush mounting
• 2.53kg
• Protective Level

  IP 65

• Power Supply Method12 VDC, 2A
• Working Temperature-30 °C to +60 °C (-22 °F to +140 °F)
• Working Humidity10% to 90%
• Dimensions413mm ×175.2mm × 48.2mm
• Battery0
• Application EnvironmentOutdoor
• Power Consumption≤ 18 W
