Camera

Image Sensor 1/2.8” 2Megapixel progressive scan CMOS
Effective Pixels 1920(H)x1080(V)
RAM/ROM 256MB/32MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual, 1/3~1/100000s
Minimum Illumination
0.02Lux/F2.4 (Color,1/3s,30IRE)
0.08Lux/F2.4 (Color,1/30s,30IRE)
0.01Lux/F2.4 (B/W,1/3s,30IRE)
0.04Lux/F2.4 (B/W,1/30s,30IRE)
S/N Ratio More than 50dB
IR Distance N/A
IR On/Off Control N/A
IR LEDs N/A

Lens

Lens Type Fixed
Mount Type Board-in
Focal Length 2.1mm
Max. Aperture F2.0
Angle of View H: 132° , V:69°
Optical Zoom N/A
Focus Control N/A
Close Focus Distance 0.4m
DORI Distance
Lens Detect Observe Recognize Identify
2.1 mm 36m(118ft) 14m(46ft) 7m(23ft) 3.5m(11ft)
Pan/Tilt/Rotation
Pan/Tilt/Rotation Range Pan:-30˚~30˚; Tilt:0˚~80˚; Rotation:0˚~360˚
Intelligence
IVS Tripwire, Intrusion, Object Abandoned/Missing
Advanced Intelligent Functions Face Detection, People Counting

Video

Compression H.265+/H.265/H.264+/H.264
Streaming Capability 3 Streams
Resolution
1080P(1920×1080)/1.3M(1280×960)/
720P(1280×720)/D1(704×576/704×480)/
VGA(640×480)/CIF(352×288/352×240)
Frame Rate
Main Stream: 1080P (1~25/30fps)
Sub Stream: D1(1~25/30fps)
Third Stream: 1080P(1~25/30fps)
Bit Rate Control CBR/VBR
Bit Rate H.264: 24~9472Kbps
H.265: 14~5632Kbps
Day/Night Auto(Electronic) / Color / B/W
BLC Mode BLC / HLC / WDR(120dB)White Balance Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control Auto/Manual
Noise Reduction 3D DNR
Motion Detetion Off / On (4 Zone, Rectangle)
Region of Interest Off / On (4 Zone)
Electronic Image Stabilization
(EIS) N/A
Smart IR N/A
Defog N/A
Digital Zoom 16x
Flip 0°/90°/180°/270°
Mirror Off / On
Privacy Masking Off / On (4 Area, Rectangle)

Audio

Compression G.711a/ G.711Mu/ AAC/ G.726

Network

Ethernet RJ-45 (10/100Base-T)

Protocol

HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP;
FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS;
UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP;
IGMP; SNMP
Interoperability ONVIF, PSIA, CGI
Streaming Method Unicast / Multicast
Max. User Access 10 Users /20 Users

Edge Storage

NAS
Local PC for instant recording
Mirco SD card 128GB
Web Viewer IE, Chrome, Firefox, Safari
Management Software Smart PSS, DSS, Easy4ip
Smart Phone IOS, Android
Certifications
Certifications
CE (EN 60950:2000)
UL:UL60950-1
FCC: FCC Part 15 Subpart B
E-mark(ECE-Regulation No.10)
EN50155

Interface

Video Interface N/A
Audio Interface Built-in Mic
RS485 N/A
Alarm N/A

Electrical

Power Supply DC12V, PoE (802.3af)(Class 0)
Power Consumption < 3.5W
