CAMERA

Image Sensor: 1/2.7″ 5MP CMOS
Effective Pixels : 2592 x 1944
RAM/ROM: 512 MB/128 MB
Scanning System: Progressive
Electronic Shutter Speed : Auto/Manual 1/3s~1/100,000s
Minimum Illumination: 0.003 Lux@F1.0
Illumination Distance: 30m
Illumination Control: Auto/Manual
Illumination LEDs: 1 (Warm Light)

LENS

Lens Type: Fixed-Focal
Mount Type: M12
Focal length: 2.8mm
Max. Aperture: F1.0
Angle of View: H:103° V:53°
Optical Zoom: N/A
IRIS Type: Fixed
Close Focus Distance: 1.2m
DORI Distance : Detect:67.4m, Observe:27m, Recognise:13.5m, Identify:6.7m

PAN/TILT/ROTAION RANGE

Pan/Tilt/Rotaion Range : Pan:0-360°, Tilt:0-78°, Rotation:0-360°

PROFESSIONAL INTELLIGENCE

Perimeter Protection (IVS): Tripwire, Intrusion (Human/Vehicle detection)
Intelligent search : Work together with Smart NVR to perform/refine intelligent search, event extraction and merging to event videos

VIDEO

Compression: H.265/H.264/H.264H/H.264B/MJPEG (sub stream)
Streamng Capability: 3 Streams
Resolution: 5MP, 4MP, 3MP, 2MP, 1.3MP, 720P, D1, CIF
Frame Rate : Main Stream: 5MP@20fps Sub Stream: D1@25/30fps Third Stream: 1080P@25fps
Bit Rate Control: CBR/VBR
Bit Rate: H.264: 32~8192Kbps H.265: 19~8192kbps
Day/Night : Auto(ICR) / Colour / B/W
BLC Mode : BLC / HLC / WDR(120dB)
White Balance: Auto / Natural / Street Lamp / Outdoor / Manual
Gain Control: Auto / Manual
Noise Reduction : 3D DNR
Motion Detection : Off / On
Region of Inferest (ROI): Off / On
Smart IR : Support
Flip: 0°/90°/180°/270°
Mirror: Off / On
Privacy Masking: Off / On

AUDIO

Compression: G.711a/G.711Mu/G.726/AAC/G.723

NETWORK

Ethernet: RJ-45 (10/100Base-T)
Protocol: HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP, SMTP; FTP; DHCP; DNS; DNS; PPPoE; IPv4/v6; SNMP; QoS; uPnP; NTP
Interoperability : ONVIF (Profile S/G/T), CGI, Milestone, Genetec, P2P
Streaming Method : Unicast/Multicast
Max. User Access : 20 Users
Edge Storage : NAS, FTP, Micro SD (256GB)
Web Viewer: Internet Explorer, Chrome, Firefox, Safari (versions newer than Safari 12)
Management Software : Smart PSS, DSS, DMSS
Smart Phone : IOS, Anrdoid

INTERFACE

RS485: N/A
Alarm : 1 Alarm input & 1 Alarm output
Audio Interface : Built-in Mic, 1 x Audio Input, 1x Audio Output

ELECTRICAL

Power Supply: PoE (802.3af), DC12V
Power Consumption: Max: 7.3W(DC12V) 8W(PoE)

ENVIRONMENTAL

Operating Conditions : -40°C to +60°C
Storage Conditions : -40°C to +60°C
Ingress Protection : IP67

CONSTRUCTION

Casing : Metal, Plastic
Dimensions : 122 x 110.9mm
Net Weight: 0.75kg
Gross Weight : 0.92kg
