Camera

• Image Sensor2 MP CMOS image sensor
• Max. Resolution1920 (H) ×1080 (V)
• Min. Illumination0.005 Lux@(F1.2, AGC ON), 0 Lux with IR
• Shutter TimePAL: 1/25 s to 1/50, 000 s,NTSC: 1/30 s to 1/50, 000 s
• Day & NightIR cut filter
• Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
• Signal SystemPAL/NTSC

Lens

• Lens Type2.8 mm, 3.6 mm, 6 mm
• Focal Length & FOV106° (2.8 mm), 82° (3.6 mm), 51° (6 mm)
• Lens MountM12


• Image Parameters SwitchSTD/HIGH-SAT
• Image SettingsBrightness, Sharpness, 3D DNR, Mirror, Smart IR
• Frame RatePAL: 1080p@25fps,NTSC: 1080p@30fps
• Day/Night ModeAuto/Color/BW (Black and White)
• Wide Dynamic Range (WDR)120 dB
• Image EnhancementWDR, BLC, HLC
• AGCHigh/Medium/Low

Interface

• Video OutputSwitchable TVI/AHD/CVI/CVBS

General

• MaterialPlastic
• Dimension165 mm × 62 mm × 58 mm (6.50″ × 2.44″ × 2.28″)
• 153 g (0.34 lb.)
• Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
• LanguageEnglish
• Power Supply12 VDC ±25%,*You are recommended to use one power adapter to supply the power for one camera.
• ConsumptionMax. 4.6 W
• IR RangeUp to 30 m

• Approval
• ProtectionIP66
