Camera

• Image Sensor4 MP CMOS
• Max. Resolution1920 (H) × 1080 (V)
• Min. Illumination0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
• Shutter Time2560 (H) × 1440 (V)
• Day & NightAuto/Color/BW (Black and White)
• Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360°
• Signal SystemPAL/NTSC

Lens

• Lens Type2.8 mm, 3.6 mm, 6 mm fixed lens
• Focal Length & FOV100.2° (2.8 mm), 88° (3.6 mm), 56.9° (6 mm)
• Lens MountM12


• Image SettingsBrightness, Sharpness, DNR, Mirror, Smart IR
• Frame Rate

  PAL: 1080p@25fps, 4 MP@25fps

  NTSC: 1080p@30fps, 4 MP@30fps

• Day/Night ModeIR cut filter
• Wide Dynamic Range (WDR)Support
• Image EnhancementBLC

• Supplement Detection(PIR)
• PIR RangeUp to 20 m

Interface

• Video OutputSwitchable TVI/AHD/CVI/CVBS

General

• MaterialPlastic
• DimensionØ 85.4 mm × 76.12 mm (Ø 3.38″ × 2.67″)
• 120 g (0.26 lb.)
• Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
• LanguageEnglish
• Power Supply12 VDC ± 15%
• ConsumptionMax. 4 W
