Camera

• Image Sensor 4 MP CMOS image sensor
• Max. Resolution2560 (H) × 1440 (V)
• Min. Illumination0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
• Shutter Time1/25 (1/30) s to 1/50,000 s
• Day & NightIR cut filter
• Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
• Signal SystemPAL/NTSC

Lens

• Lens Type 2.8 mm to 12 mm
• Focal Length & FOV108.4° to 32.6°
• Lens MountΦ14


• Image Settings Brightness, Sharpness, DNR, Mirror, Smart IR
• Frame RatePAL: 4 MP@25fps, 1080p@25fps,NTSC: 4 MP@30fps, 1080p@30fps
• Day/Night ModeAuto/Color/BW (Black and White)
• Wide Dynamic Range (WDR)Digital WDR/105 dB
• Image EnhancementBLC
• AGCHigh/Middle/Low/Off

Interface

• Video OutputSwitchable TVI/AHD/CVI/CVBS

General

• MaterialEnclosure: Plastic,Main Body: Metal
• DimensionΦ 120 mm × 105.06 mm (Φ 4.72″ × 4.16″)
• 450 g (0.99 lb.)
• Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
• LanguageEnglish
• Power Supply12 VDC ± 15%
• ConsumptionMax. 5.2 W
• IR RangeUp to 40 m

Approval

• ProtectionIP66
