Ruijie RG-AP810-L Wireless Access Point WIFI6 มาตรฐาน ax, 2×2 MIMO, ความเร็วสูงสุด 1.775Gbps, Port Lan Gigabit รองรับการ Managed แบบ Standalone/ Ruijie Cloud Controller/ Hardware Controller
*** ผู้รับเหมาโครงการต้องการราคาพิเศษสนใจติดต่อ ***
เบอร์มือถือ : 063-1963553 ไอดีไลน์ : ifocusshop
RG-AP810-L
คุณสมบัติ
Dimensions (W × D × H) |
220mm x 220mm x 49mm |
Weight |
Device : 0.6kg |
Installation |
Ceiling / Wall |
Anti-theft Lock |
Support |
Radio Specifications |
|
Radio |
Dual-radio dual-band: |
Operating Band |
Radio1: Radio2 : Note: vary depending on different countries |
Max Throughput |
Radio1:2.4GHz,0.574Gbps |
Antenna Type |
Integrated Omnidirectional |
Antenna Gain |
2.4GHz: 3dBi |
Transmit Power |
20dBm |
Adjustable Power |
1dBm |
Modulation |
OFDM:BPSK@6/9Mbps,QPSK@12/18Mbps,16-QAM@24Mbps,64-QAM@48/54Mbps |
Interfaces |
|
Interfaces |
1 10/100/1000M BASE-T Ethernet Port, PoE In (Support IEEE 802.3af) |
Bluetooth |
BT 5.1 |
Management Port |
1 RJ45 Console Port |
LED Indicator |
1 LED Indicator |
Reset Button |
Support |
Power |
|
Power Supply |
Local Power Supply (DC 48V/0.6A) ไม่มี POE Injector และ Adapter ในชุดอุปกรณ์ |
Power Consumption |
12.95W |
Environment |
|
Temperature |
Operating Temperature: -10°C~50°C |
Humidity |
Operating Humidity: 5%~95% (non-condensing) |
IP Rating |
IP41 |
Safety Standard |
GB 4943.1-2011,IEC 62368-1 |
EMC Standard |
EN 300386,GB/T 19286-2015,GB/T 17618-2015 |
Software Specifications |
|
WLAN |
Maximum Clients: 512 |
Security |
Support PSK and Web authentication |
IP |
IPv4: Support Static and DHCP IP Address |
Operation & Management |
Support Wireless LAN Controllers: |
